Specs
| Brand | Dorian Tool |
| Manufacturer's Part Number | 73310150630 |
| Hand of Holder | Right Hand |
| Toolholder Style | MTAN |
| Rake | Negative |
| Ranke Angle | -7 |
| Series | Multi-Option |
| Shank Width (Inch) | 1" |
| Shank Width (Decimal Inch) | 1.0000 |
| Shank Height | 1" |
| Shank Height (Inch) | 1.0000 |
| Overall Length (Inch) | 6" |
| Overall Length (Decimal Inch) | 6.0000 |
| Insert Compatibility | TNM 432 |
| Multi-Use Tool | No |
| Insert Holding Method | Pin & Clamp |
| Back of Bar to Cutting Edge (Inch) | 1" |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.0000 |
| Head Length (Decimal Inch) | 1.3750 |
| Insert Inscribed Circle (Inch) | 1/2 |
| Insert Inscribed Circle (Decimal Inch) | 0.5000 |
| Toolholder Material | Steel |
