Specs
| Brand | Dorian Tool |
| Manufacturers Part Number | 73310169911 |
| Insert Style | CNMG |
| Insert Size | 543 |
| Material | Carbide |
| Inscribed Circle (Decimal Inch) | 0.6250 |
| Inscribed Circle (Inch) | 5/8" |
| Thickness (Decimal Inch) | 0.2500 |
| Thickness (Inch) | 1/4" |
| Corner Radius (Decimal Inch) | 0.0469 |
| Corner Radius (Inch) | 3/64" |
| Manufacturers Grade | DKC15RT |
| Coating | TiN/TiCNB/Al2/TiO2/3Al2O3 |
| Material Grade | C1/C2 |
| Chip Breaker | KER |
| Insert Length (Decimal Inch) | 0.6496 |
| Hole Diameter (Decimal Inch) | 0.2500 |
| Hole Diameter (mm) | 6.35 |
| ISO Number | CNMG-160612-KER-DKC15RT |
| Rake | Negative |
| Relief Angle | 0 |
| Coating Process | CVD |
| Manufacturers Catalog Number | CNMG-543-KER-DKC15RT |
| Included Angle | 80 |
| Cutting Direction | Neutral |
| Maximum Depth of Cut (Decimal Inch) | 0.4720 |
| Maximum Depth of Cut (mm) | 11.99 |
| Insert Holding Method | Pin & Clamp |
| Cutting Edge Style | Honed |
| MultiUseTool | No |
| Shape | Diamond |
